Industrial Fluid Testing Refractometers

Portable testers are ideal for applications including metalworking coolants and lubricants, heat-treating fluids, hydraulic fluids, firefighting foam and plating baths.

• Automatic temperature compensation provides accurate readings without correction tables or temperature measurement
• Temperature-compensation range, 15° to 38°C (59° to 100°F)
• Large, easy-to-read scales and depth of field
• Portable: no batteries or power cord required
• Rugged, chemical-resistant housing

IFT10HP Model

• High Precision optical instrument with improved 0-10 scale 0.1 scale increments for testing low concentration synthetic cutting and grinding fluids and lubricants
• 10X focusable eyepiece
• Coated antireflection glass optical components improve illumination and shadowline contrast

• Sealed housing and eyepiece; IP67 rated water resistant and dustproof
• Black polycarbonate housing reduces stray light
• 0-30 arbitrary scale is divided into 0.5 increments; accuracy to ±0.25%
• Eyepiece with large depth of focus
• Built for production floor use; impact resistant to withstand repeated drops from three feet
